Status | Discontinued |
Logic IC Type | MULTIPLEXER |
Sub Category | Multiplexer/Demultiplexers |
Family | HC/UH |
JESD-30 Code | R-PDIP-T16 |
JESD-609 Code | e4 |
Load Capacitance (CL) | 50 pF |
Max I(ol) | 0.0060 Amp |
Moisture Sensitivity Level | NOT APPLICABLE |
Number of Functions | 4 |
Number of Inputs | 2 |
Number of Outputs | 1 |
Number of Terminals | 16 |
Operating Temperature-Min | -40 Cel |
Operating Temperature-Max | 125 Cel |
Output Characteristics | 3-STATE |
Output Polarity | TRUE |
Power Supplies (V) | 2/6 |
Prop. Delay@Nom-Sup | 33 ns |
Propagation Delay (tpd) | 165 ns |
Qualification Status | Not Qualified |
Seated Height-Max | 4.7 mm |
Supply Voltage-Nom (Vsup) | 5 |
Supply Voltage-Min (Vsup) | 2 V |
Supply Voltage-Max (Vsup) | 6 V |
Surface Mount | NO |
Technology | CMOS |
Temperature Grade | AUTOMOTIVE |
Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
Terminal Form | THROUGH-HOLE |
Terminal Pitch | 2.54 mm |
Terminal Position | DUAL |
Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
Length | 21.6 mm |
Width | 7.62 mm |
