Type Designator: 2N5485
Type of Transistor: JFET
Type of Control Channel: N -Channel
Maximum Power Dissipation (Pd): 0.35 W
Maximum Drain-Source Voltage |Vds|: 25 V
Maximum Gate-Source Voltage |Vgs|: 25 V
Maximum Drain Current |Id|: 0.01 A
Maximum Junction Temperature (Tj): 150 °C
Drain-Source Capacitance (Cd): 1 pF
Maximum Drain-Source On-State Resistance (Rds): 100 Ohm
Package: TO92
